Filamenton TECH PAHT-CF - Black - 1,75 mm
24 990 Ft
Filamenton TECH PAHT-CF - Black - 1,75 mm
Filaments manufactured according to the usual Herz formula are now available under the name FilamentOn! PAHT-CF is the ideal choice for components that have to withstand high temperatures, constant loads or friction, such as structural elements, machine parts, adapters or custom tools.
In stock
24 990 Ft
Unit price: 24 990 Ft/kg
Points earned after purchase:
500 Ft
Details
PAHT-CF (High Temperature Polyamide + Carbon Fibre) is a filament with high heat resistance and mechanical strength, developed specifically for industrial and engineering applications. The carbon fibres mixed into the polyamide matrix significantly improve the material's rigidity, dimensional stability and wear resistance, while retaining some of the polyamide's flexibility.
Where to use it:
- Industrial components, fittings, machine parts
- Components operating in heat-stressed or abrasive environments
- Prototypes that already approximate the final material properties
Where not to use:
- For decorative or low-stress, detailed prints
- With Bowden extruders – direct drive and hardened nozzle recommended due to the abrasive effect of the filament
Data
Color
Brand
Filamenton
Weight
1 kg
Diameter
1.75 mm
Material
PA
Item number
FA1SD02GDA2E0
Weight
1.5 kg/spool
Additional data:
The spool weighs 230 grams.
Recommended printing parameters for conventional printers (e.g. Ender 3, Prusa i3, Anycubic Mega):
- Head temperature: 265-275°C
- Bed temperature: 80-90°C
- Cooling: 0–20% (low airflow recommended)
- Print speed: 40 mm/s
- The use of an enclosed printing space is strongly recommended, especially for larger prints, to reduce warping.
- Head temperature: 260–275 °C *
- Bed temperature: 70–80 °C
- For closed, heated chambers, chamber temperature: 50 °C
- Cooling: 0–20%
- Print speed: up to <120 mm/s if the printer has adequate thermal stability
Data sheet
